Team Associated RC10 4WD KIT 6040
Experience the Evolution of an Icon – The Ultimate 4WD Race Buggy

---

Overview

Step into racing history with the iconic RC10—now fully transformed into a high-performance 4WD off-road buggy. Born from the vision of Team Associated founder Roger Curtis and refined with decades of racing expertise, this kit delivers everything you need in one complete package. Simply add your preferred electronics, and you’re set to dominate the track!

---

A Legacy Reimagined

• Heritage in Racing:
  Originally a 2WD legend, the RC10 made its mark at the inaugural IFMAR Off Road World Championships. Racing ace Jay Halsey clinched first place in the 2WD class and nearly swept the 4WD class driving a prototype version in Del Mar, California.
• Innovation Inspired by History:
  Although Team Associated focused on 2WD for years, the desire for a true 4WD experience lived on. Leveraging insights from the B74 and that groundbreaking prototype, our engineers have created an authentic 4WD RC10—ending the need for conversion kits or mismatched parts.

---

What’s in the Box – Complete 4WD RC10 Kit

Build a genuine Team Associated race buggy from the 90s with modern engineering:

• Chassis & Structure:
  • Gold anodized 6061-T6 aluminum monocoque tub chassis for exceptional durability and low center of gravity
  • Smooth undercarriage with special gearboxes for maximum ground clearance
• Power & Drivetrain:
  • Front and rear Stealth® transmissions with adjustable ball differentials
  • Race-proven V2 slipper clutch system for reliable power transfer
  • Front and rear CVA driveshafts and a durable low-friction center belt tension system
• Suspension & Handling:
  • Fully adjustable four-wheel independent suspension with hard-anodized, fluid-filled coil-over shocks
  • Precision-molded, dyeable nylon suspension components
  • Long front A-arm/Ball Joint design allowing fine tuning of static camber, camber rise, caster, ride height, and spring rate
• Wheels & Tires:
  • Vintage 4WD spike tires for front and rear
  • Front 2.2” 12mm hex wheels and matching rear wheels
• Body & Aerodynamics:
  • Clear polycarbonate ProTech body featuring a driver figure
  • 5.5” high-downforce Lexan® race wing for enhanced stability
• Additional Enhancements:
  • New 4WD-specific shock towers (front and rear)
  • Updated rear bulkhead, chassis stiffener, and carbon fiber rear transmission brace
  • Adjustable 3.5mm turnbuckles and HD metric ball studs throughout
  • All-new front caster and spindle assembly plus a 4WD specific bell crank system
  • Precision bearings installed throughout for smooth performance

---

Build Requirements (Electronics & Extras Not Included)

To complete your race-ready machine, you’ll need to provide:

• Power & Control:
  • 1:10 scale 540-size electric RC car motor
  • 1:10 scale radio control electronic speed control
  • 7.4V-7.6V 2S LiPo battery (fits “shorty” battery dimensions; standard or low-profile)
  • Battery charger for your chosen battery
• Radio & Steering:
  • 2-channel transmitter, 2-channel receiver, and steering servo
  • 4 AA batteries for the RC radio
• Finishing Touches & Tools:
  • Lexan-specific spray paint for the body
  • 1:10 scale off-road wheels and tires (if not using the provided vintage spikes)
  • Additional items: Silicone Shock Fluid, Silicone Diff Fluid, Body Scissors (#1737), Reamer (#1499) or Hole Punch, FT Wrench Set (#1519), Hobby Knife, Needle Nose Pliers, Wire Cutters, Soldering Iron, and Calipers or a Precision Ruler

---

Technical Specifications

• Power Source: Electric
• Terrain: Off-Road
• Body Style: Buggy
• Scale: 1:10
• Assembly Level: Kit (Full assembly required; see build requirements)
• Dimensions:
  • Length: 381mm (15 in)
  • Width: 241mm (9.49 in)
  • Wheelbase: 273mm (10.75 in)
• Drive: 4WD
• Weight: Varies based on build configuration

---

Why Choose the RC10 4WD KIT 6040?

• All-in-One Solution: No more juggling separate kits or aftermarket parts—everything you need is in one box.
• Race-Proven Performance: Every component is designed and tested for competitive off-road racing.
• Customizable & Tunable: Fine-tune your buggy’s handling and performance to match any track conditions.
• Built on a Legacy: Own a piece of RC history, reinvented for modern racing thrills.

Rev up your racing experience and bring home a true legend. Add the RC10 4WD KIT 6040 to your cart today and get ready to unleash unmatched performance on the track!

•
•
